Descripción
Detalles del producto
MarcaTotalSource
Starter typeeccentric
Type of headP
Voltage (V)12
Power (kW)1.4
Neck diameter D1 (mm)74
Pinion diameter D2 (mm)28.8
Number of teeth9
Direction of rotation of the pinionclockwise
Overall length of the starter L (mm)187
Distance between pinion and flange L2 (mm)20
Distance drive cover L4 (mm)32
Number of holes2
Position of fixation holes50-20-00
Distances between fixation holes115
Diameter mounting holes D3 (mm)11.7
Oil sealedNO
Peso3.86
